ALUX BS16 16KN SHACKLE INSULATOR
BS16 16 kN shackle insulator for low-voltage distribution. Ratings and test reports on request; container-load supply and private marking.
Low voltage Ceramic electronic components BS ED-2B
porcelain shackle insulators
- are used at the end of distribution lines or at sharp turns where there is excessive tensile load on the lines. These insulators can be mounted either in the vertical or horizontal position.
- Insulators are widely used devices, and their connecting fittings are also required to be interchangeable. In addition, the technical standards of butterfly insulators also require various electrical, mechanical, physical and environmental condition change tests on insulators according to different models and service conditions, as well as environmental condition change tests, so as to test their performance and quality.
Our services
- Factory direct prize
- ANSI BS GB IEC DIN AS standard
- Free samples
- Timely delivery
- Customer design
Shackle insulators | | |
Type | | ED-2B |
Dimensions | | |
Leakage distance | mm | 64 |
Mechanical Values | | |
Transverse Strength | kn | 16 |
Electrical Values | | |
Low frequency dry flashover voltage | kv | 25 |
Low frequency wet flashover voltage | kv | 13 |
Packing and Shipping Data | | |
Net weight,approximate | kg | 0.50 |
Typical Applications
Where ALUX BS16 16KN SHACKLE INSULATOR is commonly specified:
- Overhead distribution lines and rural electrification projects
- Substation and transformer yard line hardware
- Utility maintenance and replacement programmes
- Line hardware kits supplied alongside conductor and fittings
- Contractor and tender supply for grid operators
Sourcing Notes
- MOQ and lead time are confirmed per configuration and order quantity.
- Samples can be arranged for evaluation before volume orders.
- Technical datasheets and dimensional drawings are provided per configuration.
- Mixed models can be combined in one container; packing lists and carton marking are prepared per line item.
OEM / Private Label
- Private-label housing colour, moulding and marking for volume orders.
- Retail packaging, hang tags, labels and barcodes produced to your artwork.
- Cable length, connector configuration and jacket colour configurable per programme.
- Documentation and marking prepared for the destination market.
FAQ
Q: What standards does this insulator comply with?
This range is manufactured to the ANSI class shown in the product designation. Test reports and dimensional drawings are provided on request for the specific class ordered.
Q: Can mechanical and electrical ratings be confirmed before ordering?
Yes. The ratings listed on this page are the catalogue values for the class ordered. Batch test data and inspection reports can be supplied with the shipment.
Q: Is mixed-class container loading possible?
Mixed classes and mixed insulator types can be combined in one container. Packing lists and marking are prepared per line item.
Send target quantity, destination market, required ratings and packaging requirement to request a quotation.
